ValOre Reports Further Encouraging Metallurgical Testing Results from Pedra Branca PGE Project: 91% palladium recoveries in cyanide leach and 82% platinum recovered in 32% mass in gravity sort


November 9, 2020


Vancouver, B.C. ValOre Metals Corp. (“ValOre”; the “Company”; TSXV: VO; OTC: KVLQF; Frankfurt: KEQ0) today announced preliminary metallurgical results for cyanide leach and Falcon Ultra-Fine (“UF”) testwork for ValOre’s 100%-owned Pedra Branca Platinum Group Element (“PGE”) Project in northeastern Brazil.

“We are extremely pleased with both the high palladium recoveries achieved with cyanidation tests and the gravity concentration tests which showed more than 80% of the platinum recovered in 32% of the mass,” stated ValOre’s Chairman and CEO, Jim Paterson. These favorable and complimentary results significantly increase the optionality related to future development of the Pedra Branca project and they provide real impetus for ValOre to continue to perform tests to optimize conditions and improve metallurgical recoveries.”

Highlights from Cyanide Leach and Falcon UF Gravity Tests at Pedra Branca

  • Hot cyanide metallurgical test recoveries of 84.4%, 88.5% and 91.7% palladium (“Pd”) were achieved;
  • Falcon UF gravity test work was very effective at concentrating platinum (“Pt”) with 73.3% Pt recovered in only 9.6% of the mass and 82.6% Pt recovered in 32.1% of the mass;
  • Falcon UF gravity concentration may serve to optimize conditions required for the Platsol™ process (see news release date November 2, 2020) by favorably rejecting acid-consuming minerals, and consequently, three subsequent Platsol™ optimization tests have been initiated.

PGE Cyanidation Testwork

Palladium and platinum are readily soluble in a cyanide leach solution under certain chemical conditions. To assess the potential of cyanide leaching as a means to recover PGEs at Pedra Branca, three initial 48-hour hot cyanide leach tests were conducted at SGS Lakefield, Ontario (“SGS”). These tests were conducted on: 1) composite drill core sample from the Curiu 2PGE+Au deposit (100,000oz at 1.93 g 2PGE+Au/t); 2) an outcrop sample from the Trapia 2PGE+Au deposit (219,000oz at 1.19 g 2PGE+Au/t); and 3) tailings material collected from the first Falcon UF Gravity Concentrator test (see “Falcon UF Gravity Separation” below). Recoveries of 84.4%, 88.5% and 91.7% Pd were achieved in 48-hour leach experiments. See Table 1 below for a summary of cyanidation results, and Table 2 below for a description of sample details.

The hot cyanide leach tests were performed with the following conditions:

  • Grind size = 20-30 μm (P80)
  • Pulp density = 33% solids (w/w)
  • Pulp temperature = 50°C
  • Cyanide concentration = 20 g/L NaCN (maintained)
  • Dissolved Oxygen = 20 mg/L (maintained)
  • Retention time = 48 hours
  • Kinetic solution subsamples assayed for Pt and Pd after ~6, 24 and 48 hours

Table 1: Summary of Hot Cyanide Leach Results

Sample Tailing from Test % Extraction
Platinum Palladium
6 h 24 h 48 h 6 h 24 h 48 h
Curiu Core -- 1 2 2.6 81 88 91.7
Trapia West Outcrop -- 2 3 4.2 47 74 84.4
Curiu Core G1 5 5 7.2 83 90 88.5

Table 2: Description of Sample Details

Sample Type Source Weight
Received
Pd
(g/t)
Pt
(g/t)
Rh
(g/t)
Au
(g/t)
3PGE+Au
(g/t)
Historical Drill Core Curiu Deposit 20-25 kg 3.83 6.86 0.25 0.24 11.2
Outcrop Curiu Deposit 20-25 kg 7.86 3.95 0.45 0.30 12.6
Outcrop Trapia West Deposit 20-25 kg 21.6 17.0 0.25 0.83 39.6

The strong leachability of Pd in all three tests warrants subsequent cyanidation tests aimed at improving the performance of Pt recoveries. The addition of chloride and/or iodine as an additive in future testing may promote reaction activity and this could positively impact the recoveries of both Pt and Pd.

About Cyanidation of PGEs

Further information about cyanide leaching can be found in the link below:

https://www.sgs.ca/en/mining/metallurgy-and-process-design/cyanidation-technologies/cyanide-leaching

Falcon UF Gravity Separation

Previous mineralogical studies of Pedra Branca mineralized ultramafic rocks suggest a very fine nature to the PGE minerals (<9 micrometer (“μm”)) and thus multiple rounds of testwork have been initiated to assess the potential to upgrade feed material by means of a fine grind (-20 to -38 μm) followed by gravity separation using the Falcon UF Gravity Concentrator. The primary objective is to scavenge ultra-fine mineral particles that are typically rejected from conventional gravity processing circuits as slimes.

The first round of Falcon UF testwork (“G1”) was completed on a sample of historical drill core from the Curiu 2PGE+Au deposit (NI 43-101 resource of 100,000oz 2PGE+Au at 1.93 g/t). A summary of the samples tested is included in Table 2 above. Platinum responded very favorably to Falcon UF Gravity concentration, with 73.3% Pt separated into only 9.6% of the mass, 82.6% Pt separated into 32.1% of the mass, and 57.8% Pt on the first mass pull (4.6% of the mass). Palladium responded less favorably to Falcon UF concentration, with 47.7% Pd recovered in 32.1% of the mass. See Figure 1 and Table 3 below for a summary of G1 test results, which were run under the following test protocols: 5 kg feed at -38 μm, 10-15% solids with ~ 3 litres/minute pulp feed rate.

  • 300 G-Force centrifugal pressure
  • Recover Pass 1 Concentrate and retain
  • Repass Pass 1 Tailing
  • Repeat for a total of 8 passes – expected mass recovery of 20-25% in total
  • Filter, dry and weigh all products and submit for assay (8 concentrates, 1 tailing), including Cr, Pt and Pd
  • Metallurgical balance relating mass recovery to PGE recovery

Figure 1: Summary Graph of G1 Falcon UF Gravity Test Results

Figure 1

Table 3: Summary Table of G1 Falcon UF Gravity Test Results

Product Mass Assays, g/t Distribution %
g % Pt, g/t Pd, g/t Cr, % Pt Pd Cr
Pass 1 Concentrate 226.7 4.6 44.5 21.9 15.1 57.8 15.0 8.6
Pass 1+2 Concentrate 477.3 9.6 26.8 17.9 16.8 73.3 25.9 20.1
Pass 1-3 Concentrate 707.1 14.2 19.0 15.1 17.1 77.0 32.3 30.2
Pass 1-4 Concentrate 921.6 18.5 15.0 13.2 16.9 79.0 37.0 39.0
Pass 1-5 Concentrate 1121.0 22.5 12.5 11.9 16.4 80.2 40.4 46.1
Pass 1-6 Concentrate 1297.9 26.1 10.9 11.0 16.0 81.2 43.3 52.0
Pass 1-7 Concentrate 1455.6 29.2 9.8 10.3 15.6 82.0 45.5 56.9
Pass 1-8 Concentrate 1600.1 32.1 9.0 9.8 15.4 82.6 47.4 61.6

Given the strong performance of Pt concentration in the G1 test, a subsequent round of Falcon UF concentration testwork (“G2”) was performed, aimed at further improving recoveries by a sequential coarse-to-fine grind. G2 was designed to examine the response of coarsely ground (~100 µm P80) material to standard gravity recovery techniques (Wilfley table), followed by fine grinding of the tailing (P80 = ~20 µm) and processing at high G-Force with the Falcon UF test procedure. This assumes that the PGEs were predominantly associated with chromite and that coarse chromite may concentrate somewhat efficiently relative to the lighter matrix minerals.

Platinum once again responded well to the combined Wilfley + Falcon UF process, with 76.4% recovered in 30.6% of the mass (Wilfley concentrate + Falcon pass 1 concentrate), and 86.9% recovered in 56.1% of the mass in the combined Wilfley + 4 pass Falcon concentrate. Palladium showed a slight improvement to G1 results, but required a higher mass pull, with recovery curves flattening at ~30% mass pull. The Wilfley stage did not show a marked improvement on G1 results. CLICK HERE for Figure 2 and Table 4 for summaries of the G2 test results.

The strong performance of Pt in both the G1 and G2 Falcon UF gravity tests, combined with strong leachability of Pd seen in the three cyanidation tests presents two highly complementary processes to concentrate and recover Pd and Pt at Pedra Branca. High-priority follow-up testwork is planned to further optimize conditions and improve metallurgical recoveries.

About Falcon UF Gravity Separation

Further information about Falcon UF gravity separation can be found in the link below:

https://minerals.seprosystems.com/equipment/falcon-uf-gravity-concentrators/

ABOUT SGS

SGS is the world’s leading inspection, verification, testing and certification company. SGS is recognized as the global benchmark for quality and integrity. With more than 89,000 employees, SGS operates a network of more than 2,600 offices and laboratories around the world.

SGS fit-for-purpose solutions encompass the skills of qualified geologists, geostatistician, analytical chemists, mineralogists, metallurgists, process engineers and mining engineers brought together to provide accurate and timely mineral and process evaluation services across the entire mining life cycle.
